Seven Tips to Identify a Quality Cellular Amplifier

Wilson Electronics outlines seven tips for selecting a quality cellular amplifier to reduce dropped calls, increase data rates and ensure cellular signals stay within reach.

1. Bi-Directional Amplification

Select a cellular amplifier that is bi-directional, meaning an amplifier that boosts both the cell site's incoming down link signal and outgoing up link signal. Some amplifiers on the market only boost the down-link signal to the phone, with no amplification of the up link signal. In this scenario, users will show an increase in bars and might be able to receive calls, but will not have the power to reach back to the cell site for a reliable call. High power up-link amplification yields two benefits - better call reliability and longer battery life.

2. High Down-Link Receive Sensitivity

Receiver sensitivity is an amplifier's ability to pick up weak signals that a typical cell phone may not hear. The higher the receiver sensitivity and amplifier can provide the better. Buyer beware, some amplifiers manufacturers claiming to have high receiver sensitivity are touting numbers collected in perfect cellular signal scenarios. Quality amplifiers are tested in real world, weak signal, environments to ensure unsurpassed receiver sensitivity.

3. High Up link Output Power

Building Booster System DiagramThe lack of output power from the phone to the cell site is the reason most dropped calls occur. Lowering output power is the easy and low-quality method to prevent oscillation and to keep cost down through less expensive components and simpler designs. By cutting these corners, many amplifiers on the market today deliver less output power than a typical cell phone or data card. Higher output power, with no corners cut, ensures the strongest possible cellular connections.

4. Oscillation Detection and Shutdown

Similar to a microphone being too close to a speaker, oscillation, also know as feedback, can be attributed to improper installation. However, improper design of a wireless amplifier can also be the cause. This oscillation can make cell sites shut down, violating FCC regulations. A violation could lead to fines imposed by the FCC and confiscation of a user's amplifier. An amplifier that has a reliable and proven method of quickly and automatically detecting oscillation and shutting down when needed will protect both the cell site and the user.

5. Cell site overload protection

A quality amplifier is capable of monitoring proximity to a cell tower and automatically adjusts it's output power to accommodate this change in distance. An amplifier operating at full power when too close to a cell tower will overload the site and impair service to a large number of users. Like oscillation, cell site overload can lead to intervention by the cellular operator and the FCC, as well as put the user at risk to costly fines and amplifier confiscation.

6. 100% Customer Satisfaction Guaranteed

Car Signal Booster DiagramIdentify a company that stands behind its products and be skeptical of sellers and manufacturers that do not offer an unconditional money back guarantee. Also, read the fine print to make sure the guarantee you are getting is legitimate. A company that stands behind its products and offers extended customer services to the end user, such as a U.S. based tech support help line, is a good indicator that the product is of high quality.

7. Design Excellence

Inquire as to the prospective supplier's engineering team. Many suppliers today are not able to maintain the extensive research and development team needed for reliable amplifier performance. Choose a vendor that has a full time engineering staff solely dedicated to the design of quality amplifiers and antennas.

Choose Wilson Electronics

Wilson Electronics delivers proven, tested cellular amplifiers for in-building and mobile applications with industry-leading performance and quality. For powerful and effective results, select Wilson signal booster systems for your mobile of fixed location installation.
