Netgear LG2200D Gateway Antennas Boosters

Netgear LG2200D Gateway Antennas Boosters

How To Improve The Cellular Signal To The Netgear LG2200D Gateway

image of a netgear lg2200dThere are several different ways to improve cellular reception to your Netgear LG2200D gateway for faster Internet speeds. You can boost the reception of your device with an external antenna or powered signal booster. Adding an external to will improve cellular reception which will improve data transfer speeds. Adding a powered cellular signal booster will improve reception even more.

We offer several options to boosting Netgear LG2200D cell reception:

  • Add an External Antenna
  • Add an Power Booster With External Antenna
  • Use a Signal Booster Repeater System - Covers multiple devices over a larger area - Home, Office, Large Buildings.

Attach External Antenna

The Netgear LG2200D has 2 antennas. The antenna connectors are both SMA Female connectors. You can remove one or both antennas and attach a higher gain external antenna. Attaching a cellular antenna to the the requires an antenna cable ending in a SMA Male.

Mounting External Antenna

Ideally, you want to place the external antenna where the cellular signal is best. It is usually better to mount the antenna outdoors if possible. Directional antennas should be permanently mounted pointing directly towards then nearest tower. An excellent antenna for 4G frequencies is the Wilson Wide Band Directional Antenna (below).

CABLE: When selecting cable, match connectors to the router (SMA) and the antenna (FME or N Type). The use of the screw on adapters "SMA Male/FME Male Adapter 971119" or "SMA Male / N Female Adapter" see product listing below) may be required.

Adding An External Antenna & Power Booster

You can also add a cellular signal booster between the external antenna and the Raven for a stronger signal than antenna alone. Consider the WilsoPro Signal 4G for use in 3G and 4G areas.

Repeater Type Systems

Another solution to improving the signal strength is to use a cellular repeater type signal booster system. These systems take the available signal outside, amplify it, then rebroadcast the signal inside. These systems do not require a direct connection to your device. They also have the added value of being able to boost the signal to other devices in the area. We list it and several different options below. You can also find more on our website: Building Cellular Repeater Systems / Mobile Cellular Repeater Systems



Raven XT External Antenna & Signal Booster System Options



  • Wilson Yagi Directional Antenna Yagi Antenna Radiation Pattern

    Wilson Wide Band Directional Building Antenna 50ohm N F

    WilsonPro

    MSRP: $89.99
    $71.99
    Wilson Wide Band Log Periodic Directional Antenna - 50 ohm. Frequency Range: 700-2700 MHz. Comes with N Female connector. 314411 / 304411 Wilson Directional Antenna, Wilson Wide Band Directional Antenna, High Gain Antenna Wilson Wide Band Log Periodic...
    SKU:
    AE314411
    MSRP: $89.99
    $71.99
  • Wilson Yagi Directional Antenna With 20 foot Cable Pointing A Building Antenna

    Wilson Wide Band Directional Building Antenna w/20ft Cable N/SMA M

    WilsonPro

    MSRP: $114.99
    $96.99
    This kit combines a Wilson Wide Band Directional Antenna PLUS a 20 Foot RG-58 Cable - SMA Male Connector. Great for improving the cell signal to cellular device with a SMA Female connector such as a Hotspot or Home Phone connect. About The Wilson Wide...
    SKU:
    AE314411-955822
    Short Description:
    Wilson Wide Band Directional Cellular Antenna and 20 Foot RG-58 Cable PLUS SMA Male Connector
    MSRP: $114.99
    $96.99
  • Wilson 955815 RG-58 15ft Cable

    Wilson 955815 RG-58 15ft Cable SMA F / SMA M

    Wilson Electronics

    MSRP: $24.99
    $23.99
    15 Foot RG-58 cable with SMA Male connector on one end and SMA Female connector on the other. Use as an extension cable for antennas. WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
    SKU:
    AB955815
    Short Description:
    15ft RG-58 Cable with SMA Male and SMA Female connectors.
    MSRP: $24.99
    $23.99
  • Wilson RG-58 20ft Cable N Male / SMA Male

    Wilson RG-58 20ft Cable With N Male / SMA Male Connectors

    Wilson Electronics

    MSRP: $29.99
    $27.99
    20 ft RG-58 low loss coax cable. Perfect for cellular antennas and amplifier cable. Has SMA Male connector on one end an N-Male connector on the other. 20 ft RG-58 Low Loss Coaxial Cable RG-58 Low-Loss Coaxial Cable For indoor / outdoor use. Attenuates...
    SKU:
    AB955822
    Short Description:
    20 ft RG-58 Cable with N Male and SMA Male connectors.
    MSRP: $29.99
    $27.99
